Maintaining your Air Conditioner

An air conditioner's filters, coils, and fins require maintenance for the unit to function effectively and efficiently throughout its years of service. Neglecting necessary maintenance ensures a steady decline in air conditioning performance while energy use steadily increases.



Air Conditioner Filters

The most important maintenance task that will ensure the efficiency of your air conditioner is to routinely replace or clean its filters. Clogged, dirty filters block normal airflow and reduce a system's efficiency significantly. With normal airflow obstructe, air that by passes the filter may carry dirt directly into the evaporator coil and impair the coil's heat-absoring capacity. Replacing a dirty, clogged filter with a clean one can lower your air conditioner's energy consumption by 5% to 5%.

Some types of filters are reusable;others must be replaced. They are available in a variety of types and efficiencies. Clean or replace your air conditioning system's filter or filters every month or two during the cooling season. Filters may need more frequent attention if the air conditioner is in constant use, is subjected to dusty conditions, or you have fur -bearing pets in the house.





ERROR CODES



F0 - In Defect of Refrigerant / Refrigerant Leakage Protection

- When refrigerant is insufficient and the valve is blocked, indoor unit of air conditioner will display FO malfunction and stop operation. This function effectively protects the whole unit and safeguard the compressor against any damages occured due to high temperature result in flurione leakage

- Indoor evaporator temperature sensor works abnormally;

- The unit had been plugged up somewhere.



F1 - Indoor Ambient Temperature Sensor is Open/Short-Circuited

- The unit will stop operation as it reaches the temperature point;

- The wiring termianal between indoor evaporator temperature sensor and main board is loosened or poorly contacted;

- There short circuit due to trip-over of the parts on controller;

- Indoor ambient temperature sensor is damaged. (Please check it by referring to the resistance table for temperature sensor)



F2 - Indoor Evaporator Temperature Sensor is Open/Short-Circuited

- The unit will stop operation as it reaches the temperature point;

- The wiring terminal between indoor evaporator temperature sensor and main board is loosened or poorly contacted;

- There is short circuit due to trip-over of the parts on controller;

- Indoor evaporator temperature sensor is damaged. (Please check it by referring to the resistance table for temperature sensor)



F3 - Outdoor Ambient Temperature Sensor is OPen / Short-Circuited

- The wiring terminal between outdoor condenser temperature sensor and controller is loosened or poorly contacted;

- Outdoor ambient temperature sensor is damaged.



F4 - Outdoor Condenser Temperature Sensor is OPen / Short-Circuited

- The wiring terminal between outdoor condenser temperature sensor and controller is loosened or poorly contacted;

- Outdoor condenser temperature sensor is damaged.



F5 - Outdoor Discharge Temperature Sensor is OPen / Short-Circuited

- The wiring terminal between outdoor condenser temperature sensor and controller is loosened or poorly contacted;

- Outdoor discharge temperature sensor is damaged.



C4 - Malfunction Protection of Jumper Cap (Outdoor)

- There is not jumper cap on the main board

- Jumper cap is not inserted properly and tightly;

- Jumper cap is damaged



C5 - Malfunction Protection of Jumper Cap (Indoor)

- There is not jumper cap on the main board

- Jumper cap is not inserted properly and tightly;

- Jumper cap is damaged



E1 - High Pressure Protection of System

- Refrigerant was super abundant

- Poor heat exchange (including filth blockage of heat exchanger and bad radiating environment);

- Ambient temperature is too high.



E3 - Low Pressure Protection of Compressor

- The main board and display board are not connected well;

- The LPP terminal on the mainboard is not connected well with the high pressure switch;

- The refrigerant is insufficient;

- The wiring of high pressure switch is loosened or high pressure switch is damaged



E4 - High Discharge Temperature Protection of Compressor

- Abnormal rotation speed of outdoor motor / air intake;

- System is normal but the compressor discharge temperature sensor is broken;



E5 - Overcurrent Protection (Only for cooling capacity above 12,000btu/h)

- Unable supply voltage. Normal fluctuation shall be within 10% of the rated voltage on the nameplate

- Supply voltage is too low and load is too high;

- Measure the current of live wire on main board. If the current isn't higher than the overcurrent proctection value, please check the controller;

- The indoor and outdoor heat exchanges are too dirty or the air inlet and air outlet are blocked;

- The fan motor is not running. Abnornal fan speed; fan speed is too low or the fan doesn't run;

- THe compressor is not run normally. There is abnormal sound, oil leakage or the temperature of the shell is too high;

- There is blockage in the system (filth blockage, ice plug, greasy blockage, Y-valve hasn't been open completely)



E6 - Communication Malfunction

- Malfunction of indoor / outdoor mainboard;

- Reconnect the wire or replace the connection wire according to the wiring daigram.



E8 - Overload Malfunction

- Outdoor and indoor heat exchangers are too dirty or the air inlet / outlet is blocked;

- Fan motor is not working. Abnormal fan speed; fan speed is too low or the fan doesn't run;

- Compressor doesn't work normally. Strange noise or leakage occurs. Temperature of the shell is too high;

- System is blocked inside (dirt block, ice block, oil block, Y-valve not fully open)

- Temperature sensor of main board doesn't sense correctly.



U8 - Zero-crossing inspection circuit malfunction of the IDU fan motor

- Operation of remote controller or control panel is available but the unit won't act;

- Quick de-energization and energization. Wrong judgement by the controller because the electric-discharging of capacitor is slow;

- Zero-crossing inspection circuit of main board for controller is abnormal.



H3 - Overload Protection for compressor

- Outdoor and indoor heat exchangers are too dirty or the air inlet / outlet is blocked;

- Fan motor is not working.Abnormal fan speed; fan speed is too low or the fan doesn't run;

- Compressor doesn't work normally. Strange noise or leakage occurs. Temperature of the shell is too high;

- System is blocked inside (dirt block, ice block, oil block, Y-valve not fully open);

- High pressure switch is abnormal;

- The refrigerant is leaking and cause overheating protection to compressor.



H6 - Blocked Protection of IDU Fan Motor

- IDU fan, ODU fan, compressor and electric heat tube stop operation. Horizontal louver stops at the current position;

- The feedback / control terminal of PG motor is not connected tightly;

- Fan blade rotates unsmoothly;

- Malfunction of motor;

- Main board is broken.



H8 - Over-Blow Protection (Only for Portable Air Cond)

- Refer to the indication of instruction to discharge the water of chassis.
